Sonic Distribution Panels

How to Order

Equalizer 9 Full Panels EQ9F

SD9F Panel

These unique Distribution Panels may be applied to ceilings or walls. They are 9 inches deep and are designed to distribute sonic energy in the high, middle and low ranges (down to 70 Hz). They effectively distribute sonic energy and attenuate room peaks to create a more even, comfortable listening environment.
Dimensions
Depth: 9in, Length: 94in, Width: 34in, 150lbs

Equalizer 18 Full Panel

SD18F Panel

These unique Equalizer 18 Panels may be applied to ceiling or walls. They are 18 inches deep and designed to distribute sonic energy in the high, middle and low ranges. Depending on the number of panels and the mounting arrangement, these Equalizer 18 Panels can effectively distribute sonic energy down to below 30 Hz.
Dimensions
Depth: 18in, Length: 88in, Width: 37in, 150lbs

Equalizer 18 Full Panel

SD18L, SD18C, SD18R Sectional Panels

These unique Equalizer 18 Panels may be applied to ceiling or walls. They are 18 inches deep and designed to distribute sonic energy in the high, middle and low ranges. Depending on the number of panels and the mounting arrangement, these Equalizer 18 Panels can effectively distribute sonic energy down to below 30 Hz.
Dimensions
Depth: 18in, Length: 36in, Width: 37in, 70lbs

SD6 Squares

These innovative Equalizer Squares are specifically designed to focus on the middle to high frequencies found in most modern office environments. They are designed to be easily installed in existing drop grid ceiling systems, or mounted directly to the wall. They effectively distribute sound from multiple sources and directions.
Dimensions
Depth:9in, Length: 23.75in, Width: 23.75in, 22lbs

Equalizer 18 Full Panel

SD9A, SD9B, SD9C, SD9D

These recessed wall panel sections are created from our Broadband Sonic Equalizer 9 Panels. They have been modified to fit between 2"X 8" wall studs, set on 9.5 inch centers. The recessed design reduces projection of the wall panels to 2.5 inches beyond the wall plane. These panels can be covered by stretch fabric to complement any desired decorum.
Dimensions
Depth: 9in, Length: 94in, Width: 7in, 80lbs

Special Order

Equalizer 18 Full Panel

Acoustic Chandeliers

Our Acoustic Chandeliers feature full-size Sonic Distribution 18 broadband distribution panels mounted on each side. 12-inch wide vertical gaps between the SD panels are covered with perforated aluminum grills. The top and bottom of each Acoustic Chandelier is also covered with a perforated aluminum grill. Each Acoustic Chandelier is designed to be suspended from the ceiling with a cable. The proprietary design of these Acoustic Chandeliers offer superior broadband distribution of modals or standing waves. Also, reverberation time can be custom set by adding absorption materials in the center of the Acoustic Chandeliers.

Special Order



Options and Colors

Paint Colors

All diffusion panels come in a neutral tan color. However, any diffusion panel can be painted without affecting their performance. Golden Acoustics offers 35 optional colors for an additional charge per panel. Custom colors are available are made available from Modern Masters Paint.

Panel Colors

Custom Fabric Coverings

While Golden Acoustic panels boast a unique and beautiful fractal design, they can be covered with stretch fabric to achieve any architectural style. Golden Acoustics utilizes professional stretch fabric installer Chris Parsons.

For more information, contact cparsons@crestoneacoustical.com
